SICHUAN FOREVER RADIATION TECHNOLOGY CO.,LTD
$100≥10Roll
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF,EXW |
| Min. Order: | 10 Roll |
| Transportation: | Ocean,Land |
| Port: | Shenzhen, Shanghai ,Qingdao |
Share:
Model No.: HTPL 65
Brand: Forever
Origin: China
Certification: ISO
Place Of Origin: China
Status: New
Warranty Period: 4 Years
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: Hot Product 2019, Ordinary Product
Core Component Warranty Period: More Than 5 Years
Core Components: Plc
Core Selling Point: Easy To Operate, Famous Brand Plc, Remote Control, High Productivity, Long Service Life
Out-of-warranty Service: Video Technical Support, Online Support
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): Egypt, Turkey, United Kingdom, Italy, France, Viet Nam, Philippines, Saudi Arabia, Russia, Spain, Thailand, India, Pakistan, Indonesia, Malaysia, Australia, Kenya, Argentina, South Korea, Bangladesh, Romania, Sri Lanka, Algeria, Colombia, Uae, South Africa, Kazakhstan, Nigeria, Uzbekistan
Applicable Industry: Building Material Shops, Manufacturing Plant, Farms, Machinery Repair Shops, Energy &Amp; Mining
Showroom Location (in Which Countries Are There Sample Rooms Overseas): Egypt, Germany, Indonesia, Australia, Morocco, Algeria, Ukraine, Pakistan, Kenya, Sri Lanka, Kyrgyzstan, Nigeria, Romania, Argentina, India, Philippines, Bangladesh, Uzbekistan, South Africa, Tajikistan, Kazakhstan, Uae, Saudi Arabia
Operate Temperature: HTPL 65
HSS Width: 300mm,350mm,450mm,500mm
Thickness: 2.0mm,2.2mm,2.5mm
Type: Open type with closure patch
Layer: 3PE
Applications: Oil gas pipelines
Key Point: Cross-linked
Color: Black
Usage: Field joint coating
Standard: DIN30672
| Selling Units | : | Roll |
| Package Type | : | Roll in carton |
| Picture Example | : |
|
| Download | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
Forever heat shrink tsleeves consists of a crosslinked polyolefin backing, coated with a protective, heat active anti-corrosion adhesive which effectively bonds to steel substrates and common pipeline coatings including polyethylene and fusion bonded epoxy.
HT60 is superior performance heat shrinkable products designed for corrosion protection on field applied girth-weld joints of buried and exposed steel pipelines operating up to 65°C.The inner layer is two-components Epoxy Primer which coated on steel pipe; Intermediate level is special hot melt adhesive ;Outer layer is modified radiation crossing linking polyethylene backing.
The product is well above the domestic anticorrosive professional standards and reaches the standard requirement of EN12068，DIN 30672，ISO 21809-3 and ASTM as well.
The epoxy Primer is a corrosion protection layer to improve cathodic disbonding resistance, which is applied to cleaned and dry steel surface.
Heat shrink wrap Sleeves provide great corrosion protection,
Superior resistance to Cathodic Disbandment and excellent durability against abrasion and chemical attack.
The result is effective, good performance of sealing, wide application,
easy to operate and preheating temperature,,long term protection against corrosion.
HT 65 is a wraparound sleeve with a separate closure
Cross-linked backing provides superior abrasion, mechanical and chemical attack resistance.
Excellent resistance to Cathodic Disbondment to ensure long-term corrosion protection.
Sichuan Forever main products has Heat Shrinkable Sleeves, Pipe Repair Material,Liquid Epoxy Coatings,Visco-Elastic Coating Materials,Cold-Applied Polymeric Tape and other Wrapping Materials Application Tooling.
3LPE Heat Shrink Sleeves data sheet:
Test standard Unit 3PE 65 Adhesive Softening point ASTM E28 ℃(℉) 95 Lap shear @23℃ EN12068 N/cm2 450 Lap shear @23℃ EN12068 N/cm2 25 Backing Specific gravity ASTM D792 g/cm3 95 Tensile strength ASTM D638 MPa (psl) 24 Elongation ASTM D638 % 425 Hardness ASTM D2240 Shore D 55 Abrasion resistance ASTM D 1044 Mg 35 Volume resistance ASTM D257 Ohm-cm 1017 Dielectricvoltage breakdown ASTM D149 Kv/mm 27 Sleeves Impact EN12068 J >8 Indentation EN12068 mm 0.1 Peel adhesion ASTM D1000 N/cm 120 Peel adhesion EN12068 N/cm >140 Cathodic disbondment ASTM G8 Mm rad 3 Water absorption ASTM D 570 % 0.05 Low Temp.flexbility ASTM D2671-C ℃(℉) >-32(-26) Fully recovered T thickness Mm(mil) 1.9(77) Fully recovered L thickness Mm(mil) 2.4(96) Fully recovered S thickness Mm(mil) 3.0(121)
