Heat-Shrinkable Pipe & Pipeline Protection Products

 Available from Corrosion Control Products Company

All of the heat-shrinkable products application was done above ground. It means that the condition for the working were very good to apply and to inspect every surface of the coating. The heating of the surface was uniform. After application of the coating the pipes were buried to the depth of 1.5 m to the top of the pipe.

The typical value of the commercial mastic heat shrinkable sleeve is about 200 kPa.

Heat Shrinkable Sleeves covered 3LPE Heat Shrink Sleeves，2PE Heat Shrink Tape，3LPP Wrap Around Sleeve

HDD Heat Shrink Wrap Sleeves,Shrinkable Tape Closure Patch

Product profile

Heat Shrink Sleeves with closure patch is designed for corrosion protection on field applied girth-weld joints of buried and exposed steel

pipelines operating 50°C to 80°C，The inner layer is two-components Epoxy Primer which coated on steel pipe; Intermediate level is

special hot melt adhesive ;Outer layer is modified radiation crossing linking polyethylene backing.

Sleeves type

Heat shrink sleeves with closure patch , open type sleeves are installed before joining the pipe ends by sliding the coat from a free end of

the pipe onto the area to be coated. It is designed for corrosion protection of flanges, casings, bell and spigot joints and other high profile

couplings.

Specification( mm )

Pipeline size: from Ø 30mm to Ø 1000mm

Sleeves width: 100mm, 150mm,200mm, 300mm,450mm,500mm,600mm,900mm

Ø711----Joint or pipeline Diameter

Note: The Size can be ordered according to customers’ demand
