SICHUAN FOREVER RADIATION TECHNOLOGY CO.,LTD
$50≥100Roll
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF,EXW |
| Min. Order: | 100 Roll |
| Transportation: | Ocean,Land |
| Port: | Qingdao ,Shenzhen, Shanghai |
Share:
Model No.: 2PE
Brand: Forever
Origin: China
Certification: ISO
Place Of Origin: China
Grade: Industrial Grade
Adhesive: Hot meld adhesive, Hot melt adheive
Matched With: Closure patch
Cut Width: 300mm,350mm,450mm,500mm
Length: 30M
Backing Materials: Cross-linked polyethylene
Usage: Field joint coating anticorrosion
Applications: Oil gas pipelines
Thickness: 2.0mm,2.2mm,2.5mm
Standard: DIN30672
| Selling Units | : | Roll |
| Package Type | : | Rolls+carton+pallet |
| Picture Example | : |
|
| Download | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
2PE Heat shrink have mainly three types, it suitable for pipe operating temperature, 60 ℃，80 ℃ and 120 ℃
2 PE Heat Shrink Tape installed by wrapping the tape on the pipe joints ,fittings ,bends ,elbows etc .After the shrinking of the tape ,the closure patch should be installed onto the overlap of the tape.consists low pre-heated special rubber adhesive and thick-wall irradiated cross linked polyolefin. When heated the backing layer shrinks and the adhesive flows and forms a reliable corrosion protection seal onto metal and adjacent coating surfaces.
2 PE heat shrink tape is a special accessory for heat-shrinkable wraparound sleeve PE.
Heat Shrinkable Sleeves covered 3LPE Heat Shrink Sleeves，2PE Heat Shrink Tape，3LPP Wrap Around Sleeve HDD Heat Shrink Wrap Sleeves,Shrinkable Tape Closure Patch
Features & Benefits
Long term corrosion protection.
Non hardening and non cracking.
Fast application and high performance.
Excellent chemical resistance
Excellent resistance to shear forces
Mechanical protection and moisture resistance.
Test standard Unit Adhesive Softening point ASTM E28 ℃(℉) 110 Lap shear @23℃ EN12068 N/cm2 450 Lap shear @23℃ EN12068 N/cm2 25 Backing Specific gravity ASTM D792 g/cm3 95 Tensile strength ASTM D638 MPa (psl) 24 Elongation ASTM D638 % 425 Hardness ASTM D2240 Shore D 55 Abrasion resistance ASTM D 1044 Mg 35 Volume resistance ASTM D257 Ohm-cm 1017 Dielectricvoltage breakdown ASTM D149 Kv/mm 27 Sleeves Impact EN12068 J >8 Indentation EN12068 mm 0.1 Peel adhesion ASTM D1000 N/cm 120 Peel adhesion EN12068 N/cm >140 Cathodic disbondment ASTM G8 Mm rad 3 Water absorption ASTM D 570 % 0.05 Low Temp.flexbility ASTM D2671-C ℃(℉) >-32(-26) Fully recovered T thickness Mm(mil) 1.9
60/80/120
