SICHUAN FOREVER RADIATION TECHNOLOGY CO.,LTD
$5≥500Roll
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF |
| Min. Order: | 500 Roll |
| Transportation: | Ocean,Land |
| Port: | Shenzhen, Shanghai ,Qingdao |
Share:
Model No.: HSS
Brand: Forever
Origin: China
Certification: ISO
Place Of Origin: China
Plastic Molding Process Type: Extruding
Processing Service: Moulding, Cutting
Backing Materials: Cross linked PE backing
Usage: Field joint coating anticorrosion
HSS Width: 300mm,350mm,450mm,500mm
Operate Temperature: HTPL 65
Color: Black
Applications: Oil gas pipelines,onshore,offshore,
Key Point: heat shrink
Adhesive: Hot melt adheive
Standard: DIN30672
| Selling Units | : | Roll |
| Package Type | : | Rolls+carton+pallet |
| Picture Example | : |
|
| Download | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
The corrosion coating shall consist of a high build epoxy applied to the steel surface, followed by a wrap-around heat shrinkable sleeve, and shall be suitable for an operating temperature not exceeding 80°C in wet conditions.
Cross-linked Wrap-around Heat Shrinkable Sleeve on the weld joint shall be long enough for 24” OD pipe so as to overlap onto the mainline coating by a minimum on each side of the weld joint.
The width of Heat Shrinkable Sleeves shall be 450mm
The corrosion Coating is a wrap-around Heat Shrinkable Sleeve, black in color and shall be suitable for an operating temperature of 140ºF in wet conditions.
Sleeve coating
The inner surface of the sleeves shall be coated with a controlled thickness of an adhesive which in combination with the modified Epoxy Primer, will bond to and seal to the steel pipe and common yard applied medium temperature yard coatings, such as epoxy.
Backing
The Sleeve and closure backings shall be fabricated from a thermally stabilized, extruded radiation cross-linked heat shrinkable polyethylene. The Backing of the sleeve and closure shall be homogeneous and free from flaws, defects, pinholes, bubbles, cracks and inclusions.
Heat Shrinkable Sleeves covered 3LPE Heat Shrink Sleeves，2PE Heat Shrink Tape，3LPP Wrap Around Sleeve HDD Heat Shrink Wrap Sleeves,Shrinkable Tape Closure Patch
