Heat Shrink Wrap Tape For Pipe Joints

Name: heat shrink sleeves package
Uploaded: 2023-11-27T08:48:02+08:00
Description: heat shrink sleeves package

$5≥100Set/Sets

Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,EXW,FCA
Min. Order:	100 Set/Sets
Transportation:	Ocean,Land,Air,Express
Port:	Shanghai,Shenzhen,Qingdao

Option:

8 inch
12 inch
16 inch
24 inch

Contact Now

Product Description

Product Attributes

Brand: Forever

Origin: Sichuan, China

Certification: ISO

Place Of Origin: China

Classification: Hot Melt Adhesives

Application Field: Construction

Color: Black

Thickness Range: 1.5 mm to 3.0 mm

Width Range: 50 mm to 1200 mm

Standard: ISO 21809-3,EN 12068,AWWA C

Packaging & Delivery

Selling Units	:	Set/Sets
Package Type	:	plastic bag+carton + Pallet
Picture Example	:

The file is encrypted. Please fill in the following information to continue accessing it

heat shrink sleeves package



Product Description

Sichuan Forever main products has Heat Shrinkable Sleeves, Pipe Repair Material,Liquid Epoxy Coatings,Visco-Elastic Coating Materials,Cold-Applied Polymeric Tape and other Wrapping Materials Application Tooling.

Forever Cross Linked Heat Shrinkable Sleeves consists of three layers, Epoxy primer layer, adhesive layer, film backing.

Epoxy Primer： Liquid epoxy, solvent free two component.

Adhesive: High shear strength co-polymer adhesive

Film backing: Radiation cross linked. High density polyethylene

Features

Excellent resistance to cathodic disbandment.

Long term corrosion protection.

Non hardening and non cracking.

Mechanical protection and moisture resistance.

Excellent chemical resistance

Excellent resistance to shear forces

Fast application and high performance.

Construction	Three Layers system
Three Layers System	First Layer:- Liquid Epoxy, Solvent free two component Second Layer:- High Shear strength copolymer adhhesive Third Layer:- Radiation cross linked, high density polyethylene with permanent Change Indicator
Maximum Operating Temperature	85 Degree Centigrade
Min Preheat Temperature	70 Degree Centigrade
Compatible Line Coating	PE/FBE/Coal Tar/DFBE
Standard	ASTMD 638,ASTM D 2240,ASTM D 149,ASTM D 570,ASTM D 1000,ASTM D 870,ASTM D 2671,ASTM E 28,ASTM G 14,EN 12068,ISO 21809-3
Sleeve Backing thickness	0.80mm,1.0mm,1.2mm,1.5mm
Hot melt adhesive thickness	0.60mm,0.7mm,0.8mm,1.0mm,1.2mm,1.5mm
Sleeve Width	300mm,350mm,450mm,470mm,500mm,520mm,600mm
Sleeve Length for one joints	DIX1.07+0.12m
PE Backing Density	≥0.95 gm/cc
Hardness of PE backing	≥50 Shore D
Ring and Ball Softening Point of adhesive	≥90°C
Lap Shear Strength at 10mm/min	≥3.0N/sq.mm
Peel Strength of installed sleeve 10mm/min	≥5.0 N/mm

3LPE 60C Heat Shrink Sleeves is superior performance heat shrinkable products designed for corrosion protection on field applied girth-weld joints of buried and exposed steel pipelines operating up to 60°C
The inner layer is two-components Epoxy Primer which coated on steel pipe; Intermediate level is special hot melt adhesive ;
Outer layer is modified radiation crossing linking polyethylene backing.
3LPE 60C Heat Shrink Sleeves is developed by this Company on the basis of the original product. It is the first of the same kind in China. Currently, the product is well above the domestic anticorrosive professional standards and reaches the standard requirement of EN12068 and ASTM as well.
3LPE 60C Heat Shrink Sleeves product uses the polyethylene produced by ATOFINA of France and many other auxiliary materials as base materials. The mechanic performance targets such as indentation resistance, impact resistance and tensile strength have reached EN12068 standards. And its aging-resistance and ultraviolet rays-proof performance have met the requirements of ASTMD638 standards.
